The FNIRSI 2C53T is a highly versatile, handheld 3-in-1 instrument that tightly integrates a Dual-Channel 50MHz Digital Oscilloscope, a 19,999-Count Precision Multimeter, and a DDS Function Signal Generator. Built on an advanced FPGA + ARM + ADC hardware architecture, this portable tool replaces a bench worth of bulky electronics test gear. It serves as a go-to diagnostic lab for field technicians, embedded systems engineers, and electronics hobbyists debugging hardware on the move.

Specifications

1. Digital Oscilloscope

• Channels: Dual Channel (Independent execution per channel)
• Analog Bandwidth: 50MHz
• Real-time Sampling Rate: 250MS/s
• Storage Depth: 1Kpts
• Input Impedance: 1Mega Ohm
• Vertical Sensitivity: 10mV/div - 10V/div (at 1X magnification)
• Timebase Range: 10ns/div - 20s/div
• Maximum Input Voltage: ± 400V (Peak AC + DC)
• Triggering Modes: AUTO / Normal / Single
• Trigger Types: Rising Edge / Falling Edge
• Display Configurations: Y-T Mode (Standard Time-Domain), Rolling Mode, and X-Y Mode (Lissajous Patterns)
• Signal Math: 8 basic arithmetic operations + FFT (Fast Fourier Transform) spectrum analysis
• Advanced Features: Hardware cursor measurements, infinite afterglow (persistence rendering), and one-click AUTO set.

2. Digital Multimeter

• Display Resolution: 4½ Digits, 19,999 Counts (True RMS)
• DC Voltage Range: 1.9999V / 19.999V / 199.99V / 1000V (± 0.5% + 3)
• AC Voltage Range: 1.9999V} / 19.999V / 199.99V / 750.0V (±1.0% + 3)
• DC/AC Current Range: 19.999mA / 199.99mA / 1.9999A / 9.999A
• Resistance Range: 199.99Ohm to 19.999Mega Ohm
• Capacitance Range: 9.999nF to 99.99mF
• Auxiliary Testing Modes: Diode forward drop, fast audio continuity tester, and temperature sensing selection (-55℃ to 1300℃).

3. DDS Function Signal Generator

• Available Waveforms: 13 distinct profiles (Including Sine, Square, Triangle/Sawtooth, Half-wave, Full-wave, Exponential Rise/Fall, Sinker Pulse, Lorentz wave, and DC offset).
• Output Frequency Range: 0Hz - 50kHz
• Frequency Step Precision: 1Hz
• Output Amplitude Range: 0V - 3V Peak-to-Peak (Vpp)
• Duty Cycle Adjustment: 0% - 100% (For rectangular/square configurations)

4. General System Specs

• Display Panel: 2.8-inch HD color LCD (320 x 240 resolution)
• Power Source: Built-in 3000mAh rechargeable Lithium battery
• Operational Runtime: Up to 6 hours of continuous field testing
• Charging Interface: USB Type-C (5V / 1A input)
• Data Connectivity: USB-to-PC interface for screenshot image exports and firmware flashes.

Key Upgrades Over the Predecessor (2C23T)

The 2C53T represents a massive design overhaul compared to the legacy 2C23T model:

• Five-Fold Bandwidth Boost: The analog input capability scales aggressively from 10MHz up to a true 50MHz, allowing you to analyze much faster logic clocks and communications buses.
• Aggressive Sampling Spike: Real-time sampling capabilities jump from 50MS/s to 250MS/s, ensuring cleaner wave rendering with significantly less aliasing at high frequencies.
• Expanded Display Analysis: Incorporates X-Y Mode for calculating component phase shifts via Lissajous curves and adds adjustable signal persistence (afterglow) to trap intermittent signal glitches.
• Multimeter Precision Doubled: Upgraded from a 9,999-count engine to a 19,999-count true-RMS converter, significantly improving precision and resolution for low-voltage sensor lines.
• Waveform Catalog Expansion: The generator now synthesizes 13 signal shapes (up from 6), though the max frequency ceiling is optimized to 50kHz to prioritize stable amplitude accuracy over its range.

Common Applications

• On-the-Go Embedded Debugging: Troubleshooting microcontroller hardware SPI, I2C, and UART serial lines right at the machine site.
• Switch Mode Power Supply (SMPS) Tuning: Identifying high-frequency noise ripple patterns and ripple voltages on 5V, 12V, or 24V power rails.
• Audio Engineering & Repair: Injecting a 1kHz sine wave via the built-in signal generator into audio pre-amps, then capturing the output signal on the dual channels to isolate harmonic clipping or distortion.
• Automotive Electrical Diagnostics: Probing crankshaft position sensors, fuel injector pulses, and CAN-bus physical layer signal integrity.

Field Operating Tips

• Calibrate Your Probes: Before making critical high-frequency measurements, connect your 10X oscilloscope probe tip to a known square-wave reference (such as a hardware test point). Use a non-conductive tuning screwdriver to twist the probe's compensation capacitor trimmer until the corners of the square wave on screen are perfectly flat—not rounded (under-compensated) or spiked (over-compensated).
• Mind the Shared Ground Rails: The ground shields of the two oscilloscope BNC input sockets are internally connected together. When probing two separate points on a live circuit simultaneously, ensure both probe ground clips are attached to the exact same ground reference potential. Attaching them to different voltage nodes will create an instant short-circuit loop through the device and damage your circuit under test.
• Leverage the AUTO Button Wisely: If a waveform appears as a chaotic blur or falls off-screen, pressing the physical AUTO key forces the FPGA to scan the input, scale the vertical voltage grid, and calculate the ideal timebase automatically. Once the wave stabilizes, switch back to manual adjustment to lock down subtle signal transitions.
• Isolate PC Grounds While Charging: When connecting the Type-C port to a computer to export screenshots, avoid measuring high-voltage mains circuits (110V). The ground loop running through the USB cable to the PC chassis can create an unsafe current path. For high-voltage isolation safety, run the instrument entirely on its internal 3000mAh battery while probing
